Manufacture of the Armstrong Gun at Woolwich Arsenal: finish-turning a 100-pounder, 1862. Creator: Unknown.

Légende

Manufacture of the Armstrong Gun at Woolwich Arsenal: finish-turning a 100-pounder, 1862. 'The gun, being now completely built up, is carried to a lathe for the purpose of being finish-turned, as is shown in our Illustration...This is performed in a portion of a lofty and extensive building, which we were told was formerly used as a foundry for the casting of the old pattern-guns, but has been transformed into two or three large shops, in which are powerful turning-lathes and other machines used in connection with the heavier class of guns. The workman in the Engraving is seen applying a gauge to the part of the gun at which the tool is cutting. This gauging is in order to ascertain that neither more nor less is being turned off than is required, as it is essential that each gun should be the duplicate, both in external and internal dimensions, of one which is retained in the department, and sealed, as a pattern to guide the manufacture of other guns of the same nature'. From "Illustrated London News", 1862.

Date

1862

Crédit

Photo12/Heritage Images/The Print Collector

Notre référence

HRM24A08_449

Model release

NA

Property release

NA

Licence

Droits gérés

Format disponible

27,2Mo (2,6Mo) / 31,4cm x 21,7cm / 3710 x 2564 (300dpi)

Mots clés

London England people male event work job technology man men arts industry manufacturing worker metal art trade steel guy occupation British equipment weapon weapons gun guns color scale industrial factory machine machinery war craftsmanship cannon cannons workmen workman manufacture Armed Forces century iron Britain profession precision measurement newspapers press print metalwork gauge concept workshop measurements lathe B&W Army warfare machine shop machinist engraved engraving Greenwich industrial revolution Colour metalworking 19th century black & white black and white B W arsenal weaponry armed services white and black metal worker metalworker armaments British Army metalworkers nineteenth century workers metalworks The Print Collector armaments industry Armstrong gun Illustrated London News metal industry TGN Woolwich Woolwich Arsenal ILN newspaper Unknown working man 19th-century metal work scale drawing weapons industry
