'Section of the Prussian Needle Gun', c1872. Creator: Unknown.

Légende

'Section of the Prussian Needle Gun', c1872. Diagram showing cartridge chamber, needle bolt, slide block, knob, spiral spring, thumbpiece and handle of locking spring. From "The Franco-Prussian War: its causes, incidents and consequences", Volume I, by Captain H M Hozier. [William Mackenzie, London, 1872]
