Plan of the first floor of the Palazzo Podestà in Genoa, Seconda pianta del Palazzo del sigr. Luigi Centurione, print, album page, This print is part of an album., printmaker: Nicolaes Ryckmans, Antwerp, publisher: Peter Paul Rubens, provider of privilege: Spanish crown, 1622, paper, engraving, height 328 mm x width 171 mm, height 583 mm x width 435 mm, plan, architecture, hôtel, ie small palace in city - AA - civic architecture: inside, Genoa, Palazzo Podestà, A vertically oriented architectural floor plan rendered in ink on aged paper showing the layout of rooms and corridors within a rectangular building footprint, with thick hatched exterior walls and thinner interior partition walls; the drawing includes symmetrical room arrangements on left and right sides, a central large rectangular hall with a curved double-arched entrance at its top, a loggia space below the curved arches, staircases including a spiral staircase on one side, rectilinear rooms of varying sizes arranged around the central axis, and a courtyard area near the top containing four inner rectangular plots; shading, cross-hatching, dotted lines, and measured division marks indicate wall thicknesses and spatial divisions, while decorative border elements and small ornamental blocks appear at certain wall intersections.
