Longitudinal section of the Palazzo Rostan Raggio in Genoa, Taglio di a fianco solo verso ponente del Palazzo. I, print, album page, This print is part of an album., printmaker: Nicolaes Ryckmans, Antwerp, publisher: Peter Paul Rubens, provider of privilege: Spanish crown, 1622, paper, engraving, height 200 mm x width 210 mm, height 583 mm x width 435 mm, section, architectural design or model, hôtel, ie small palace in city - AA - civic architecture: inside, Genoa, Palazzo Rostan Raggio, A detailed architectural engraving of a multi-level building section showing rows of rooms with vaulted ceilings, doorways with ornate frames, staircases, arches, and structural beams; the roof structure is visible with a triangular timber truss and closely spaced rafters; interior walls are rendered with fine horizontal hatching and some rooms display balustrades or niches; shading and stippling indicate curved ceilings and recessed areas, and columns or pilasters separate adjoining spaces; portions ...
Caption

Longitudinal section of the Palazzo Rostan Raggio in Genoa, Taglio di a fianco solo verso ponente del Palazzo. I, print, album page, This print is part of an album., printmaker: Nicolaes Ryckmans, Antwerp, publisher: Peter Paul Rubens, provider of privilege: Spanish crown, 1622, paper, engraving, height 200 mm x width 210 mm, height 583 mm x width 435 mm, section, architectural design or model, hôtel, ie small palace in city - AA - civic architecture: inside, Genoa, Palazzo Rostan Raggio, A detailed architectural engraving of a multi-level building section showing rows of rooms with vaulted ceilings, doorways with ornate frames, staircases, arches, and structural beams; the roof structure is visible with a triangular timber truss and closely spaced rafters; interior walls are rendered with fine horizontal hatching and some rooms display balustrades or niches; shading and stippling indicate curved ceilings and recessed areas, and columns or pilasters separate adjoining spaces; portions of the facade reveal layered floors and cross-sections of vaults and corridors.

Credit line

Photo12/Liszt Collection

Reference

LZT26B27_343

License type

Rights managed

Available size

37.5Mb (9.5Mb) / 12.4in x 11.8in / 3715 x 3532 (300dpi)

Keywords

Longitudinal section Palazzo Rostan Raggio Genoa Taglio di fianco solo verso ponente del Palazzo I print album page part album printmaker Nicolaes Ryckmans Antwerp publisher Peter Paul Rubens provider privilege Spanish crown 1622 paper engraving height 200 mm x width 210 mm height 583 mm x 435 mm section architectural design model hôtel ie small palace city - AA - civic architecture inside detailed architectural engraving multi-level building section showing rows rooms vaulted ceilings doorways ornate frames staircases arches structural beams roof structure visible triangular timber truss closely spaced rafters interior walls rendered fine horizontal hatching display balustrades niches shading stippling indicate curved ceilings recessed areas columns pilasters separate adjoining spaces portions facade reveal layered floors cross-sections vaults corridors

Please log in to download the high resolution file
