Title
Mine drainage
Caption
Mine drainage. Man in centre left of picture is boring lengths of wood with borers and augers to form pipes. Man on centre right is working the piston rod of a suction pump to raise water from a mine. In the left foreground are lengths of pipe to be joined, and various internal pump parts.
From "De re metallica", by Agricola, pseudonym of Georg Bauer (Basle, 1556).
Woodcut.
Date
1556
Credit line
Photo12/Ann Ronan Picture Library
Reference
ARP07111_009617P
License type
Rights managed
Available size
21,7Mb (1,6Mb) / 7,1in x 11,8in / 2141 x 3543 (300dpi)
